Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    1.54
  • Stroke (in):
    1.63
  • Displacement (cc):
    49
  • Carburetion Type:
    Carburetor
  • Turbocharged:
    No
  • Supercharged:
    No
  • Number Of Carburetors:
    1
  • Compression Ratio:
    10:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    3
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    36
  • Fuel Capacity (gal):
    0.7
  • Fuel Capacity Reserve (gal):
    0.2
  • Length (in):
    51.3
  • Width (in):
    22.9
  • Height (in):
    30.5
  • Ground Clearance (in):
    6
  • Wet Weight (lbs):
    111
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    0.9
  • Front Travel (in):
    3.8
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    2.8
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    1
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Steel
  • Chromed:
    No
  • Tube / Tubeless:
    Tubed
  • Front Tire (Full Spec):
    2.50 - 10
  • Rear Tire (Full Spec):
    2.50 - 10
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Drum
  • Front Brake Diameter (in):
    3.1
  • Rear Brake Type:
    Drum
  • Rear Brake Diameter (in):
    3.1
  • Anti-Lock Brakes:
    Not Available
  • Linked Brake System Front to Rear:
    Not Available
