Specifications

• ENGINE

  add remove
  • Engine Type:
    Single-Cylinder
  • Cylinders:
    1
  • Engine Stroke:
    4-Stroke
  • Cooling:
    Air
  • Valves:
    2
  • Valves Per Cylinder:
    2
  • Valve Configuration:
    SOHC
  • Bore (in):
    1.97
  • Stroke (in):
    2.48
  • Displacement (cc):
    124
  • Carburetion Type:
    Fuel Injected
  • Turbocharged:
    No
  • Supercharged:
    No
  • Compression Ratio:
    10.0:1
• TRANSMISSION

  add remove
  • Transmission Type:
    Manual / Automatic Clutch
  • Number Of Speeds:
    4
  • Primary Drive (Rear Wheel):
    Chain
  • Reverse:
    No
  • Gear Ratio (1):
    2.5
  • Gear Ratio (2):
    1.55
  • Gear Ratio (3):
    1.15
  • Gear Ratio (4):
    0.92
• TECHNICAL SPECIFICATIONS

  add remove
  • Wheelbase (in):
    49
  • Fuel Capacity (gal):
    1
  • Length (in):
    75.2
  • Width (in):
    28.9
  • Height (in):
    39.4
  • Ground Clearance (in):
    5.4
  • Wet Weight (lbs):
    238
• SUSPENSION

  add remove
  • Front Suspension Type:
    Inverted Fork
  • Front Suspension Size (in):
    1
  • Front Travel (in):
    3.5
  • Front Adjustable Fork Pre-Load:
    No
  • Front Adjustable Rebound Damping:
    No
  • Front Central Suspension Strut:
    No
  • Steering Damper:
    No
  • Rear Suspension Type:
    Twin Sided Swing Arm
  • Rear Suspension Material:
    Steel
  • Rear Travel (in):
    3.6
  • Rear Adjustable Shock / Spring Pre-Load:
    No
  • Rear Adjustable Rebound Damping:
    No
  • Number Rear Shock Absorbers:
    2
  • Air Adjustable:
    No
• WHEELS & TIRES

  add remove
  • Wheels Composition:
    Aluminum
  • Chromed:
    No
  • Tube / Tubeless:
    Tubeless
  • Front Tire (Full Spec):
    IRC: 70/90-17 M/C 38P
  • Rear Tire (Full Spec):
    IRC: 80/90-17 M/C 50P
  • Spare Tire:
    Not Available
• BRAKES

  add remove
  • Front Brake Type:
    Hydraulic Disc
  • Front Brake Diameter (in):
    8.7
  • Rear Brake Type:
    Drum
  • Rear Brake Diameter (in):
    4.3
  • Anti-Lock Brakes:
    Standard
  • Linked Brake System Front to Rear:
    Not Available
